The Codere 250 system is a modular batch-type heat treatment line.
Designed for precise and repeatable processes such as hardening, carburizing, carbonitriding, nitriding, annealing, or tempering, the System 250 is built for manufacturers requiring high quality, flexibility, and process consistency.
Its batch-type architecture supports small to medium production series across demanding sectors including automotive, aerospace, defense, bearings, precision tooling, and general mechanical engineering.
Key product advantages
Modular & easy to expand
Reliable & high-quality results
Advanced protective atmosphere
Automatic or semi-automatic
Energy & gas efficient
High productivity & high ROI
Watch our System 250 video
The System 250 is engineered for flexibility, uniformity, and high-performance heat treatment.
Description
Modular quench, batch-type bell furnace line with independent stations for multi-process heat treatment
Protected sliding transfer into the quench (<15 s) to maintain temperature and avoid oxidation
Full process under controlled atmosphere from heating to cooling for oxidation-free + low distorsion results
Components
Batch bell ovens, quench system with protective atmosphere, washing machine, salt recuperator, customizable...
Quench tanks for water, oils, salts, polymers + optional gas quench up to 6 bar
Manipulators (manual or automatic) and HTView control for supervision, recipes, and traceability
Processes
Hardening, carburizing, carbonitriding, nitrocarburizing, annealing, tempering, nitriding, solution treatment & ageing
Applications: gears, shafts, bearings, dies, mechanical components, high-precision parts
Industries: automotive, aerospace, defense, tooling, machinery, and general manufacturing
Technical details
Max. operating temperature: 1080 °C
±5 °C (AMS 2750 Class 2-compliant)
Quench media : Water ; Oils ; Polymers ; Salt ; Gas
Semi-automatic or fully automatic
Max. load weight: up to 5000 kg
Atmospheres: nitrogen, hydrogen, methanol, other gas...
Architecture: modular sealed quench, batch-type line scalable with additional furnaces, washing units, cooling stations, or quench tanks
Useful load dimensions:
- Diameter: 200–2000 mm
- Height: 200–4500 mm
Transfer time: <15s or <5s
Suitable for fine and distortion-sensitive parts
